SW-195 Embedded Industrial SFP + 4 Port PoE+ Gigabit Ethernet Switch

  • 1x SFP & 4x Port PoE+ Gigabit Unmanaged Ethernet Switch
  • Dual Redundant, Wide Power Input: +44 V to +57 VDC
  • Low Power Consumption: 5.3 W Max
  • Operating Temperature Rating: -40 °C to +70 °C /-40 °F to +158 °F
  • Embeddable

Download SW-195 Technical Datasheet (PDF)

£149.00
Add to Cart
Buy from Reseller
Brainboxes SW-195 1x sfp & 4x port poe+ gigabit unmanaged ethernet
Brainboxes SW-195 internal circuit board view showing sfp port and certification logos
AEO Authorised Economic Operator
CAGE Code 8QCY6
CE Mark
FCC
Lifetime Support
Lifetime Warranty
Made in Great Britain
NCAGE Code U0Q96
NDAA Compliant
TAA Compliant
UKCA Mark
UL6268 Certified

Embedded PoE+ Industrial Gigabit SFP Ethernet switch.

Fast, low-cost, future-proof way to deploy long network segments. Connect to a wide variety of fibre optic and copper cable types for high-speed data connection over extended distances.

Galvanically Isolated Ethernet brainboxes-ed-593-front-panel-ethernet-port-status-leds. Automatic detection of data transmission speed: 10/100/1000 Mbps. Industrial temperature range of -40°C to +70°C (-40°F to 158°F) and dual input redundant power supply with wide voltage range means it can be powered from USB or on the 24V factory floor. Power terminal is removable with numbered pins for easy wiring. Power consumption is optimised based on the status of the link device. No software required. Ideal for factory floor, in vehicle and marine applications.

See other products the same category as SW-195: Gigabit Ethernet Switch

Download SW-195 CAD 3D Model
