ed 588 ethernet 8 digital inputs 8 digital outputs
  • 8 Digital Inputs, 8 Digital Outputs and an RS485 Gateway Port
  • Control any input or output from TTL to high voltage high current industrial devices
  • Factory floor process control and automation, Integrated DIN rail mount
  • Supports simple ASCII or industry standard Modbus TCP
  • -30°C to +80°C Temperature range
  • Software APIs for Visual Basic, C# and more
  • ED-588-datasheet (1.92 MB)
Volume Purchase? Request a Quote

Request a Quote

Description

Ethernet to DIO device: 8 non-isolated digital input channels and 8 digital output channels. Outputs each group of 4 lines has its own common rail. Powerful ARM 80 MHz, 32 Bit CPU. Offers robust and intelligent 'control side' devices that provide the interface to systems on the 24V factory floor environment, commonly referred to as 'process side'.

The device can be controlled over TCP/IP using the Modbus TCP protocol or simple ASCII commands. Additionally Brainboxes supply a suite of APIs and sample code to communicate with the device using Microsoft .NET framework Visual Basic, C#, C++, Java, Javascript, PHP and more. The device and be configured and secured from a web browser. The device can be installed as a COM Port on a Windows PC to give complete backwards compatibility essential for legacy applications.

The ED product range is designed for harsh environments. The digital output port line are implemented as protected output circuits, providing current overload and short circuit protection, voltage surge, overload and open circuit protection and over temperature protection to allow the widest possible usage and range of devices.

The outputs are good for driving hot and cold resistive loads, capacitive loads and inductive loads and are especially suited for loads with high inrush currents such as cold bulbs/lamps and motors. Typical applications are control and switching of AC and DC motors, Fans, relay drivers, pumps, Voltage Regulators and Battery Chargers, LEDs and Bulbs, Air Conditioning, Heaters and Solenoids..

Customer Feedback

Product Videos

Product 3D Models

Tech Spec

IO Channels
IO ProtocolsModbus TCP or DCON ASCII (over TCP or Virtual COM port)
Description8 Digital Inputs and 8 Digital Outputs
Digital Inputs8
Digital Outputs8
Analog Inputs0
Analog Outputs0
WatchdogWhen device comms is lost, outputs can be set to predetermined state
Power On ValuesOutputs can be set to predetermined values on power on
Safe ValuesWhen Input triggered, outputs can be automatically set to predetermined value
Digital IO
Input Logic Level 0-30.0V to +1.0V
Input Logic Level 1+2.0V to +30V
Input LatchesTriggered by user programmable positive or negative edges, stays true until acknowledged
Input CounterUser progammable- counts positive or negative transitions up to 200Hz
Digital Output TypeOpen drain transistor, protected MosFET. Short circuit protection up to 36V. Over temperature shutdown -175°C typical 150°C min
Maximum Output Load Voltage30 VDC
Maximum Output Current Sink0.85A per channel
Serial Port
Serial GatewayRS485 NuDam/ADAM compatible expansion port
Network
Number of Ports1
Network Port TypeRJ45 Jack 10/100 MHz Autosensing, Cross Over Autosensing (MDIX)
Network ProtocolsICMP, IP, TCP, DHCP, HTTP
Protection1500V Magnetic Isolation between ports and network
Power
Power InputRedundant DC Dual Power Inputs, reverse polarity protected +5 VDC to +30VDC
Power Supply 1 DescriptionGlobal Power Supply - PW-600
Power Supply 2 DescriptionPower supply PW-650
Max Input35 Volts
General
Operating Temperature Range-30 °C to +80 °C / -22 °F to +176 °F
Industrial StandardYes
Storage Temperature-40 °C to +85 °C / -40 °F to +185 °F
Galvanic IsolationNo
Power ConsumptionInput +5V to +30V DC 100mA@24V 2.5W max
Product Weight0.138 kg, 4.87 ounces
Product Dimensions129x102x23 mm, 5.1x4.0x0.9 inches
Packaged Weight0.234 kg, 8.25 ounces
Packaged Dimensions160x135x49 mm, 6.3x5.3x1.9 inches
GTIN (barcode)837324003178
Operating System Compatibility
Operating Systems
  • Microsoft Windows 10
  • Suitable for any device with a Web Browser
  • Microsoft Windows 8 32 bit & 64 bit Editions
  • Windows Server 2012
  • Raspberry Pi
  • Android
  • Windows Server 2008 R2
  • Microsoft Windows 7 32 bit & 64 bit Editions
  • iOS
  • Windows Server 2008 32 bit & 64 bit Editions
  • Windows Vista 32 bit & 64 bit Editions
  • Mac OS X
  • Windows XP 32 bit & 64 bit Editions
  • Microsoft Windows 2000
  • Linux
