UC-072

4 Port RS232 PCI Serial Card Opto Isolated TX RX GND

Discontinued

uc-072-upci-4xrs232-opto-isolated-tx-rx-gnd

Universal PCI providing four RS232 serial ports with Opto Isolation on TX RX and GND lines (RTS, CTS and all other lines are not connected). Data transfer rates up to 921,600 baud rates and the 128 byte deep transmit and 128 byte receive FIFOS, coupled with 1Mbit/s line drivers deliver uncompromising performance on your PC.Includes drivers for all Windows 32 bit and 64 bit Operating Systems, including Windows 10.

Serial Port
Serial Port	Ports	4
	Protocol	RS232
	Connector	DB9 Connector - 9 Pin Male
	UART	Brainboxes 16C958
	UART Compatibility	16750/16550/16450 backwards compatible as well as an enhanced 950 mode
	Tx FIFO Size	128
	Rx FIFO Size	128
	Operating Distance	EIA - RS232 Standard
	Cable	4 port cable (44 way D to 4x9 Pin)
Serial Port Settings
Serial Port Settings	Max Baud Rate	921,600
	Data Bits	5,6,7 or 8
	Parity	Odd, Even, None, Mark or Space
	Stop Bits	1, 1.5 or 2
	Flow Control	XON/XOFF
	Tx/Rx Modes	Point to Point
General
General	PCB Layers	4
	Form Factor	Standard Height
	Includes Printer Port	No
	Galvanic Isolation	Yes
	Power Consumption	550mA @ 5V
	Product Weight	0.076 kg
	Product Dimensions	134(l) x 120(w) x 18(h) mm
	Packaged Weight	0.654 kg
	Packaged Dimensions	200(l) x 135(w) x 80(h) mm
	GTIN (barcode)	837324002263
Operating System Compatibility
Operating System Compatibility	Operating Systems	Microsoft Windows 10 Microsoft Windows 8 32 bit & 64 bit Editions Windows Server 2012 Microsoft Windows 7 32 bit & 64 bit Editions Windows Server 2008 32 bit & 64 bit Editions Windows Vista 32 bit & 64 bit Editions Windows XP 32 bit & 64 bit Editions Microsoft Windows 2000 DOS
Interface
Interface	PCI 3.0	Peripheral Component Interface

Product Attributes

Weight	0.654 kg
Dimensions	200 × 135 × 80 mm
Ports	4 Ports
Form Factor	Standard Height
Protocol	RS232

2085
Ports: 4 Ports
Form Factor: Standard Height
Protocol: RS232
