CB-534

Industrial Isolated RS232 Booster

Boosts and Isolates RS232 Signals
Works at all data word lengths, parity options and stop bits combinations
No Software Required
Max baud rate 120,000 - Compatible with legacy equipment
-30°C to +80°C/-22ºF to +176ºF Temperature range

PDF Datasheet Download

$295.52

Add to Cart

Volume Purchase?Request a Quote

cb-534-industrial-isolated-rs232-booster

Booster for RS232 signal can extend cable length. Works with a wide voltage swing and outputs -11V to +11V signal making it suitable for legacy and non-conforming RS232 equipment. Provides isolation between two RS232 devices. This product doesn’t require any software, simply connect using the easy-wire numbered terminal blocks.

Serial Port
Serial Port	Ports	2
	Protocol	RS232
	Connector	Removable Screw terminal block connector - 3.5 mm pitch
Serial Port Settings
Serial Port Settings	Max Baud Rate	120,000
	Parity	Works at all data word lengths, parity option and stop bits combinations
	Flow Control	TXD, RXD, RTS, CTS
Power
Power	Power Input	5V - 30V DC Redundant DC Dual Power Inputs, reverse polarity protected
	Max Input	35 Volts
	Power Consumption	2.5 Watt Max
Accessory
Accessory	Compatibility	Fits all Brainboxes 34mm ExpressCards
General
General	Operating Temperature Range	-30 °C to +80 °C / -22 °F to +176 °F
	Industrial Standard	Yes
	Storage Temperature	-40 °C to +85 °C / -40 °F to +185 °F
	Galvanic Isolation	Yes
	Power Consumption	2.5W typical 110mA@24V
	Product Weight	0.11 kg
	Product Dimensions	114(l) x 99(w) x 23(h) mm
	Packaged Weight	0.206 kg
	Packaged Dimensions	160(l) x 135(w) x 49(h) mm
	GTIN (barcode)	837324004045
Operating System Compatibility
Operating System Compatibility	Operating Systems	Suitable for any device with Serial Port
