VX-023 1 Port RS422/485 ExpressCard Serial Adapter with integrated connector

Discontinued

1 Port RS422/485
ExpressCard Technology
Data rate from 110 to 921,600 baud
Fits in any 34mm or 54mm ExpressCard slot
Drivers for all popular operating systems
Lifetime Warranty and Support

ExpressCard providing one RS422/485 serial port. ExpressCard is 34mm wide and fits 34mm or 54mm slots. Data transfer rates up to 921,600 baud rates and the 128 byte deep transmit and 256 byte receive FIFOS coupled With 1Mbit/s line drivers deliver uncompromising performance on your laptop. Drivers for Windows 32 bit and 64 bit Operating Systems including Windows XP, Server 2003, Vista, Server 2008, Windows 7,8 and Windows 10.

Serial Port
Serial Port	Ports	1
	Protocol	RS422/485
	Connector	DB9 Connector - 9 Pin Male
	Tx FIFO Size	128
	Rx FIFO Size	256
	Operating Distance	RS422/485 Standard (4000 ft : 1200 metres)
	Cable	No Cable; Integrated Connector
Serial Port Settings
Serial Port Settings	Max Baud Rate	921,600
	Data Bits	7 or 8
	Parity	Odd, Even, None, Mark or Space
	Stop Bits	1 or 2
	Flow Control	RTS/CTS, XON/XOFF
	Tx/Rx Modes	Full Duplex, Half Duplex Autogating
General
General	Ruggedised	Yes
	PCB Layers	4
	ExpressCard Width	34mm (fits both 34mm and 54mm ExpressCard slots)
	Power Consumption	80mA @ 3.3V
	Product Weight	0.03 kg
	Product Dimensions	101(l) x 38(w) x 20(h) mm
	Packaged Weight	0.12 kg
	Packaged Dimensions	160(l) x 135(w) x 49(h) mm
	GTIN (barcode)	837324001471
Operating System Compatibility
Operating System Compatibility	Operating Systems	Microsoft Windows 10 Microsoft Windows 8 32 bit & 64 bit Editions Microsoft Windows 7 32 bit & 64 bit Editions Windows Vista 32 bit & 64 bit Editions Mac OS X Windows XP 32 bit & 64 bit Editions Linux
Interface
Interface	USB 2.0	480 Mb/s USB 2.0 data rates.

Software and Drivers
