UC-357 1 Port RS232 plus 1 Port RS422/485 PCI Serial Card

Name: UC-357 1 Port RS232 plus 1 Port RS422/485 PCI Serial Card - Brainboxes
Brand: brainboxes
SKU: UC-357
Price: 143.00 GBP
Availability: InStock

Built for Life Warranty

Connected for Life

Download UC-357 Technical Datasheet (PDF)

£143.00

Add to Cart

Buy from Reseller

Volume Purchase?Request a Quote

Brainboxes ES-346 rs-422485 serial connector 9-pin pinout wiring diagram with pin assignments

Universal PCI providing one RS232 port and one RS422/485 serial port. Data transfer rates up to 921,600 baud rates and the 128 byte deep transmit and 128 byte receive FIFOS, coupled with 1Mbit/s line drivers deliver uncompromising performance on your PC.Includes drivers for all Windows 32 bit and 64 bit Operating Systems, including Windows 8.

See other products the same category as UC-357: PCI Universal

Serial Port
Serial Port	Ports	2
	Protocol	RS232 + RS422/485
	Connector	DB9 Connector - 9 Pin Male
	UART	Brainboxes 16C958
	UART Compatibility	16750/16550/16450 backwards compatible as well as an enhanced 950 mode
	Tx FIFO Size	128
	Rx FIFO Size	128
	Operating Distance	RS422/485 Standard (4000 ft : 1200 metres) / EIA - RS232 Standard
	Cable	No Cable; Integrated Connector
Serial Port Settings
Serial Port Settings	Max Baud Rate	921,600
	Data Bits	5,6,7 or 8
	Parity	Odd, Even, None, Mark or Space
	Stop Bits	1, 1.5 or 2
	Flow Control	RTS/CTS, DSR/DTR, XON/XOFF
	Tx/Rx Modes	Point to Point (RS232), Full Duplex, Half Duplex Autogating, Hardware Autogating, TxD always/ RTS true enabled, RxD always enabled, RxD RTS true disabled, CTS forced true (RS422/485)
General
General	PCB Layers	4
	Form Factor	Standard Height
	Includes Printer Port	No
	Galvanic Isolation	No
	Power Consumption	550mA @ 5V
	Product Weight	0.08 kg
	Product Dimensions	136(l) x 120(w) x 18(h) mm
	Packaged Weight	0.191 kg
	Packaged Dimensions	160(l) x 135(w) x 49(h) mm
	GTIN (barcode)	837324000481
Operating System Compatibility
Operating System Compatibility	Operating Systems	Microsoft Windows 10 Microsoft Windows 8 32 bit & 64 bit Editions Windows Server 2012 Microsoft Windows 7 32 bit & 64 bit Editions Windows Server 2008 32 bit & 64 bit Editions Windows Vista 32 bit & 64 bit Editions Windows XP 32 bit & 64 bit Editions Microsoft Windows 2000 DOS
Interface
Interface	PCI 3.0	Peripheral Component Interface
