PX-157 Parallel Port Printer Low Profile PCI Express Card

LP PCIe 1xLPT Printer Port

Download PX-157 Technical Datasheet (PDF)

£121.00

Volume Purchase?Request a Quote

Brainboxes PX-157 lp pcie 1xlpt printer port

Brainboxes CC-249 lpt printer port pinout diagram showing 25 pin female connector layout

PCI Express card provides an industry standard 25 pin LPT port on a low profile connector. Drivers for Windows 32 bit and 64 bit Operating Systems including Windows 2000, XP, Server 2003, Vista, Server 2008, Windows 7, 8 and Windows 10.

NOT RECOMMENDED FOR NEW DESIGNS

See other products the same category as PX-157: PCI Express

Serial Port
Serial Port	Ports	1
	Protocol	LPT Printer
	Connector	25 Pin Parallel Port Female Connector
	UART	Oxford 950
	UART Compatibility	16750/16550/16450 backwards compatibile
	Cable
Printer Port
Printer Port	Printer Port	1
	Printer Port Protocol	LPT IEEE-1284 with SPP/PS2/EPP/ECP support
	Printer Port Connector	25 Pin Female D Connector on Fly Lead
General
General	PCB Layers	4
	Form Factor	Low Profile
	Includes Printer Port	Yes
	Power Consumption	380mA @ 3.3V
	Product Weight	0.047 kg
	Product Dimensions	80(l) x 80(w) x 18(h) mm
	Packaged Weight	0.14 kg
	Packaged Dimensions	160(l) x 135(w) x 49(h) mm
	GTIN (barcode)	837324001921
Operating System Compatibility
Operating System Compatibility	Operating Systems	Microsoft Windows 10 Microsoft Windows 8 32 bit & 64 bit Editions Microsoft Windows 7 32 bit & 64 bit Editions Windows Server 2008 32 bit & 64 bit Editions Windows Vista 32 bit & 64 bit Editions Windows XP 32 bit & 64 bit Editions
Interface
Interface	PCI Express x1, x4, x8 & x16 lane slots	PCI Express (Peripheral Component Interconnect Express), officially abbreviated as PCI-E or PCIe, is a computer expansion card standard introduced by Intel in 2004. All Brainboxes PX cards are PCI Express Base Specification 1.1 Compliant.
