CC-135 ISA 2 Port RS422/485

Name: CC-135 ISA 2 Port RS422/485 - Brainboxes
Brand: brainboxes
SKU: CC-135
Price: 150.00 GBP
Availability: InStock

Discontinued

Brainboxes CC-135 at dual velocity rs422 485

Brainboxes ES-346 rs-422485 serial connector 9-pin pinout wiring diagram with pin assignments

This half size card provides two serial ports independently configurable as RS422 with and without hand-shaking, or RS485 full or half duplex. This card has on-board zener diodes giving transient spike protection to the inputs, making the card ideal for factory automation installations. The megabaud data transfer rates and the 64 byte deep FIFO, coupled with the RS485 Half Duplex Autogating guarantees uncompromising performance and fault-free use The UART clock can be set to provide maximum baud rates of either 921,600 baud, 460,800 baud, 230,400 baud, or 115,200 baud (standard PC). Serial Solutions Device Driver CD contains software for Windows Millennium, Windows 98, Windows 95, Windows NT4, Windows 3.x, DOS and OS/2. Informative manuals and sample programs are supplied with full source code on CD!

See other products the same category as CC-135: Discontinued

Serial Port
Serial Port	Ports	2
	Protocol	RS422/485
	Connector	DB9 Connector - 9 Pin Male
	UART	TI 750
	UART Compatibility	16750/16550/16450 backwards compatibile
	Tx FIFO Size	64
	Rx FIFO Size	64
	Operating Distance	RS422/485 Standard (4000 ft : 1200 metres)
	Cable	No Cable; Integrated Connector
Serial Port Settings
Serial Port Settings	Max Baud Rate	921,600
	Data Bits	5,6,7 or 8
	Parity	Odd, Even, None, Mark or Space
	Stop Bits	1 or 2
	Tx/Rx Modes	Full Duplex, Half Duplex Autogating - Hardware Autogating
General
General	PCB Layers	4
	Form Factor	Standard Height
	Includes Printer Port	No
	Galvanic Isolation	No
	Power Consumption	550mA @ 5V
	Product Weight	0.093 kg
	Product Dimensions	awaiting
	Packaged Weight	0.268 kg
	Packaged Dimensions	awaiting
	GTIN (barcode)
Operating System Compatibility
Operating System Compatibility	Operating Systems	Microsoft Windows ME Microsoft Windows 98 Microsoft Windows NT 4.0 Microsoft Windows 95 Microsoft Windows 3.x OS/2 DOS
Interface
Interface	ISA	Industry Standard Architecture

Software and Drivers
