PX-823 PCI Express 1 Port RS232 Powered (through IDE power connector) 1 Amp POS Card

  • 1 Port RS232 Powered, up to 1 Amp selectable power through pins 1 or 9
  • Data rate from 110 to 921,600 baud
  • PCI Express
  • 128 Byte Transmit and Receive FIFOs
  • Drivers for all popular operating systems including Windows 10, 8, 7 and XP
  • Lifetime Warranty and Support

Download PX-823 Technical Datasheet (PDF)

£115.50
Add to Cart
Buy from Reseller
Brainboxes PX-823 1 port rs232 powered, up to 1 amp selectable power through
Brainboxes ES-446 rs232 serial port pinout diagram showing 9 pin male connector wiring
AEO Authorised Economic Operator
CAGE Code 8QCY6
CE Mark
FCC
Lifetime Support
Lifetime Warranty
Made in Great Britain
NCAGE Code U0Q96
NDAA Compliant
TAA Compliant
UKCA Mark

PCI Express Card providing one powered RS232 serial ports. Data transfer rates up to 921,600 baud rates and the 128 byte deep transmit and 128 byte receive FIFOS, coupled with 1Mbit/s line drivers deliver uncompromising performance on your PC. Up to 1 Amp selectable power provided through pins 1 and 9 to attached peripherals. The extra power necessary is supplied to the PCI express card directly from the PC power supply unit through a Parallel ATA (PATA – or IDE) power connector: a neat, clean and green solution. Drivers for Windows 32 bit and 64 bit Operating Systems including Windows 2000, XP, Server 2003, Vista, Server 2008, Windows 7, 8 and Windows 10.

See other products the same category as PX-823: PCI Express

Download PX-823 CAD 3D Model

PX-823 Media

PX-823 Supported Operating Systems

microsoft-windows-10
microsoft-windows-2000
microsoft-windows-7-32-bit-64-bit-editions
microsoft-windows-8-32-bit-64-bit-editions
windows-server-2008-32-bit-64-bit-editions
windows-vista-32-bit-64-bit-editions
windows-xp-32-bit-64-bit-editions
